A6814S
Code: A6814S
Category: Alternators
Manufacturer: Denso
Supplier: As-pl
STANDARD LINE
Brand new AS-PL Alternator
Size a: 35.00 mm
Size b: 13.00 mm
Size c: 58.00 mm
Amp.: 130 A
D.1: 11.00
D.2: 10.00
D.3: 10.50
Pulley: AP
L.1: 176.00 mm
Plug: PL_2802
G: 7
O.d.1: 60.00 mm
Voltage: 12 v
Reference number
| Code | Manufacturer | |
| UD30172A | As-pl | |
| 05037198AA | Chrysler | |
| 5037198AA | Chrysler | |
| 210-0624 | Denso | |
| 421000-0190 | Denso | |
| 421000-0191 | Denso | |
| A-80277 | Dixie | |
| 114232 | Farcom | |
| 11039N | Lester | |
| 11039 | Wai / Transpo | |
| 90-29-5641 | Wilson |
Usage
| Brand | Model | Type | Year | Note |
| DODGE | Ram 8.3 V10 | [505] | 01.2004-12.2004 | |
| DODGE | Ram 8.3 V10 | [505] | 01.2005-12.2005 | |
| DODGE | Ram 8.3 V10 | [505] | 01.2006-12.2006 | |
| DODGE | Viper 8.3 V10 | [505] | 01.2003-12.2003 | |
| DODGE | Viper 8.3 V10 | [505] | 01.2004-12.2004 | |
| DODGE | Viper 8.3 V10 | [505] | 01.2005-12.2005 | |
| DODGE | Viper 8.3 V10 | [505] | 01.2006-12.2006 |
