A9188


Code: A9188

Category: Alternators

Manufacturer: Ford

Supplier: As-pl

STANDARD LINE

Brand new AS-PL Alternator



Size a: 28.00 mm

Size c: 86.00 mm

Amp.: 130 A

D.1: 10.50

D.2: 11.50

D.3: 13.50

E.1: 75.50 mm

E.2: 75.50 mm

Pulley: AP

L.1: 148.00 mm

Plug: PL_3102

G: 6

O.d.1: 59.00 mm

Voltage: 12 v



Reference number

CodeManufacturer
A9188 As-pl
UD12658AAs-pl
CAL14128ASCasco
23770 DELCO
92542DELCO
A-2086Dixie
27-7576Elstock
4U2Z-10V346-ADRM Ford
5F9T-10300-AC Ford
5L8T-10300-KC Ford
5L8T-10300-KD Ford
5L8T-KCFord
5L8T-KDFord
5L8Z-10346-KA Ford
6L8T-10300-AB Ford
6L8T-10300-KA Ford
6L8T-ABFord
6L8T-KAFord
6L8Z-10346-AB Ford
6L8Z-10346-ABRM2 Ford
6L8Z-10346-ACRM Ford
6L8Z-10346-BDRM Ford
6L8Z-10346-KA Ford
6L8Z-10V346-ACRM Ford
RM4U2J-10D309-JCFord
RM6L8T-10300-AEFord
ALF3403Krauf
554825RIKuhner
AJC8-18-300B Mazda
ZZC2-18-300 Mazda
ZZC3-18-300R0B Mazda
20130192Prestolite
885.562.130Psh
20150821BNReal
2014128.0Sando
ALT161280ASIOM
8403NWai / Transpo
8403RWai / Transpo
90-02-5147Wilson
90-02-5147NWilson
ALT42490Woodauto


Usage

BrandModelTypeYearNote
FORDEscape 3.0 V601.2005-12.2007
MAZDATribute 3.0 V6 AWD[AJ]03.2000-05.2008
MERCURYMariner 3.0 V601.2005-12.2007
