S9379S
Code: S9379S
Category: Starters
Manufacturer: Bosch
Supplier: As-pl
STANDARD LINE
Brand new AS-PL Starter motor
Size a: 89.00 mm
Size b: 47.00 mm
C.1: 11.00 mm
C.2: 11.00 mm
C.3: 11.00 mm
L.1: 385.00 mm
No./teeth: 9
No./mount. holes: 3
No./mount. holes with thread: 0
O.1: 90.00 mm
O.2: 90.00 mm
O.3: 127.00 mm
Power: 3.00 kW
Rotation: CW
Voltage: 12 v
Reference number
| Code | Manufacturer | |
| UD16951S | As-pl | |
| CST10193AS | Casco | |
| 19024564 | DELCO | |
| 220312 | Era | |
| 22202 | Era | |
| 8961949 | Fiat | |
| SG0460 | Ghibaudi | |
| 1304445 | Khd | |
| 254022 | Kuhner | |
| 254022D | Kuhner | |
| 254022K | Kuhner | |
| 254022L | Kuhner | |
| 254022M | Kuhner | |
| 26024101A | Lucas | |
| 26024101ASEL | Lucas | |
| 51262017008 | Man | |
| 51262019008 | Man | |
| 500.100.093.100 | Psh | |
| 500.100.093.320 | Psh | |
| 0025841025 | Renault | |
| 008961949 | Unic-simca | |
| 240500 | Volvo |
Usage
| Brand | Model | Type | Year | Note |
| BOMAG | BW 10 A | [KHD-F4L912] | 01.1973- | |
| BOMAG | BW 15 A | [KHD-F6L912] | 01.1973- | |
| BOMAG | BW 200 | [KHD-F4L912] | 01.1973-06.1986 | |
| BOMAG | BW 4 A | [KHD-F3L912] | 01.1973-09.1984 | |
| BOMAG | BW 6 A | [KHD-F3L912] | 01.1973- | |
| MAN | D 0020 | 01.1965-12.1973 | ||
| VOLVO BM | S950 | [D50A] | 02.1966-12.1970 | |
| VOLVO BM | T800 | [D50A] | 01.1967-12.1975 | |
| VOLVO BM | T810 | [TD50A] | 03.1969-12.1975 | |
| VOLVO BM | T814 | [TD50A] | 03.1969-06.1979 | |
| VOLVO | B 705 | [D47B] | 01.1962-04.1964 | |
| VOLVO | F 84 | [D50B] | 01.1972-12.1974 | |
| VOLVO | F 84T | [TD50B] | 01.1972-10.1978 | |
| VOLVO | F 85 | [D50B] | 01.1972-12.1974 | |
| VOLVO | F 85T | [TD50B] | 01.1972-10.1978 | |
| VOLVO | F 86 | [D70B] | 06.1970-12.1974 | |
| VOLVO | F 86T | [TD70B] | 08.1970-09.1974 | |
| VOLVO | FB 84 | [D50B] | 01.1972-12.1974 | |
| VOLVO | FB 84T | [TD50B] | 01.1972-10.1978 | |
| VOLVO | FB 85T | [TD50B] | 01.1972-10.1978 | |
| VOLVO | FB 86 | [D70B] | 06.1970-12.1974 | |
| VOLVO | FB 86T | [TD70B] | 08.1970-09.1974 | |
| VOLVO | L 375 | [D47A] | 01.1959-12.1961 | |
| VOLVO | L 465 | [D47B] | 06.1961-05.1965 | |
| VOLVO | L 475 | [D47B] | 06.1961-05.1965 | |
| VOLVO | L 4751 | [D47B] | 10.1964-12.1965 | |
| VOLVO | N 7 | [TD70B] | 09.1973-07.1978 | |
| VOLVO | N 84 | [D50B] | 01.1972-08.1973 | |
| VOLVO | N 86T | [TD70B] | 08.1970-08.1973 | |
| VOLVO | NB 84 | [D50B] | 01.1972-08.1973 | |
| VOLVO | NB 86 | [D70B] | 06.1970-08.1973 | |
| VOLVO | NB 86T | [TD70B] | 08.1970-08.1973 |
