  2. A9281S



A9281S


Code: A9281S
Category: Alternators
Manufacturer: Yanmar
Supplier: As-pl
STANDARD LINE
Brand new AS-PL Alternator


Size a: 45.00 mm
Size b: 14.00 mm
Amp.: 20 A
D.1: 10.50
D.2: M8x1.25
Pulley: AP
L.1: 77.00 mm
Plug: PL_N/A
G: 1
O.d.1: 36.50 mm
O.d.2: 65.00 mm
Voltage: 12 v
W.1: 12.50


Reference number

CodeManufacturer
ALTL5473EFFE
A9281SAs-pl
UD15422AAs-pl
115463Cargo
CAL56100ASCasco
CAL56100GSCasco
2476Cevam
151-14105Dixie
AM877557John Deere
AM879144John Deere
CH15587John Deere
MIA10338John Deere
SE501822John Deere
SE501843John Deere
ALZ1990Krauf
553370RIKuhner
89212877Powermax
635.514.020.200Psh
20103001BNReal
20103001OEReal
300-10100Robert's
2056100.0Sando
2056100.1Sando
A12MA0313A2Sidat
ALT581000SIOM
ALT581000ASIOM
10939NWai / Transpo
70-29-10939Wilson
ALT42702Woodauto
11991077200Yanmar
124190-77201Yanmar
129150-77200Yanmar
12915077200Yanmar
12915077201Yanmar
12915077202Yanmar
12915077203Yanmar
17130177201Yanmar


Usage

BrandModelTypeYearNote
CASECS16B[3TNE74N]01.2003-12.2011
CASECX14[3TNE68]01.2003-12.2006
JOHN DEERE1070[4TN84]01.1989-12.1996
JOHN DEERE2243[3TNE68]01.1995-12.2005
JOHN DEERE2305[3TNV76]01.2006-12.2011
JOHN DEERE2320[3TNV76]01.2006-12.2013
JOHN DEERE2500[3TN68C]01.1999-12.2004
JOHN DEERE2500A[3TNE68V]01.2005-12.2008
JOHN DEERE2500B[FD620D]01.2009-12.2014
JOHN DEERE2500E[3TNE68V]01.2005-12.2014
JOHN DEERE252001.2006-12.2010
JOHN DEERE2653A[3TNE68]01.2003-12.2008
JOHN DEERE2653B01.2016-12.2016
JOHN DEERE337501.1994-12.1999
JOHN DEERE37501.1988-12.1993
JOHN DEERE401001.2003-12.2005
JOHN DEERE410001.1998-12.2001
JOHN DEERE411001.2002-12.2010
JOHN DEERE411501.2002-12.2010
JOHN DEERE41501.1995-12.1997
JOHN DEERE42501.1993-12.1997
JOHN DEERE44501.1993-12.1997
JOHN DEERE455[3TNA72]01.1993-12.1997
JOHN DEERE67001.1989-12.1996
JOHN DEERE77001.1989-12.1996
JOHN DEERE79001.1999-12.2007
JOHN DEERE87001.1989-12.1996
JOHN DEERE97001.1989-12.1996
JOHN DEERE99001.2000-12.2008
JOHN DEEREX47501.2002-12.2005
JOHN DEEREX48501.2002-12.2005
JOHN DEEREX49501.2002-12.2005
JOHN DEEREX57501.2002-12.2006
JOHN DEEREX575 4WD01.2002-12.2006
JOHN DEEREX58501.2002-12.2006
JOHN DEEREX585 4WD01.2002-12.2006
JOHN DEEREX595 4WD01.2002-12.2006
JOHN DEEREX70001.2002-12.2012
JOHN DEEREX710 Signature01.2016-12.2017
JOHN DEEREX72001.2006-12.2012
JOHN DEEREX720SE01.2006-12.2012
JOHN DEEREX72401.2006-12.2012
JOHN DEEREX72801.2006-12.2012
JOHN DEEREX728SE01.2006-12.2012
JOHN DEEREX72901.2008-12.2012
JOHN DEEREX730 Signature[FD750D]01.2016-12.2017
JOHN DEEREX734 Signature[FD750D]01.2016-12.2017
JOHN DEEREX738 Signature[FD750D]01.2016-12.2017
JOHN DEEREX739 Signature[FD750D]01.2016-12.2017
JOHN DEEREX748[3TNV76]01.2006-12.2012
JOHN DEEREX748SE[3TNV76]01.2006-12.2012
KOBELCOSK014[3TNA72L]
KOBELCOSK015[3TNA72L]
KOBELCOSK13SR[3TNA72L]
KOBELCOSK15SR[3TNA72L]
KOBELCOSK25SR-2[3TNE74-NYB]
MultiquipNighthawk LT12P[103.10]
