S9809S
Code: S9809S
Category: Starters
Manufacturer: Mitsuba
Supplier: As-pl
STANDARD LINE
Brand new AS-PL Starter motor
Size a: 30.00 mm
Size b: 40.00 mm
C.1: 7.00 mm
C.2: 7.00 mm
L.1: 151.00 mm
No./teeth: 9
No./mount. holes: 2
No./mount. holes with thread: 0
O.1: 34.00 mm
Rotation: CW
Voltage: 12 v
Reference number
| Code | Manufacturer | |
| UD19081S | As-pl | |
| 410-54229 | J&n | |
| 77040001000 | KTM | |
| 30808 | Lester | |
| 30808N | Wai / Transpo |
Usage
| Brand | Model | Type | Year | Note |
| KTM | 250 EXC-F | 01.2006-12.2013 | ||
| KTM | 250 EXC-F Champion Edit. | 01.2010-12.2010 | ||
| KTM | 250 EXC-F Factory Edit. | 01.2011-12.2011 | ||
| KTM | 250 EXC-F Six Days | 01.2007-12.2013 | ||
| KTM | 250 SX-F | 01.2012-12.2012 | ||
| KTM | 250 SX-F Roczen Replica | 01.2012-12.2012 | ||
| KTM | 250 XC-F | 01.2007-12.2012 | ||
| KTM | 250 XCF-W | 01.2006-12.2013 | ||
| KTM | 250 XCF-W Champion Edit. | 01.2010-12.2010 | ||
| KTM | 250 XCF-W Six Days | 01.2010-12.2011 |
